High-Tension XLPE Power Cables — 11kV & 33kV

Description :- Reliable transmission up to 33,000 volts. Built to endure high mechanical, electrical, and thermal stress. Engineered with stranded aluminium or copper conductors, XLPE insulation, semiconductor screening, armouring, and PVC sheathing — designed for tropical and high-ambient conditions.

Product Details :-

  • Type 1 :- 11 kV HT XLPE Cable
  • Voltage Grade :- 11,000 volts
  • Conductor Options :- Stranded aluminium / copper
  • Product Range :- Up to 3C x 300 sq.mm
  • Applications :- Industrial plants, substations, power distribution networks
  • Type 2: 33 kV HT XLPE Cable
  • Voltage Grade :- 33,000 volts
  • Conductor Options :- Stranded aluminium / copper
  • Product Range :- Up to 3C x 300 sq.mm
  • Applications :- High-voltage distribution, transmission lines, utilities

Features :-

  • High Voltage Performance :- Transmits power safely at 11 kV and 33 kV.
  • Superior Insulation :- XLPE insulation + semiconductor screening ensures long life and safety.
  • Armoured Protection :- Aluminium or GI steel armouring for enhanced mechanical strength.
  • Built for Tough Environments :- Performs reliably in tropical, humid & high-ambient conditions.
  • Wide Range :- Available up to 3C x 300 sq.mm in both 11kV & 33kV types.

Technical Details :-

  • Key Features
  • Conductor: Stranded Aluminium / Copper
  • Conductor Screening: Extruded semiconducting layer
  • Insulation: XLPE (Cross-Linked Polyethylene)
  • Insulation Screen: Semiconductor layer
  • Inner Sheath: PVC / equivalent
  • Armour: Aluminium (single-core) / Galvanized steel (multi-core)
  • Outer Sheath: PVC protective covering
